The POT/GAL 15 V 10 A is a high-grade potentiostat/galvanostat system for advanced electrochemical impedance spectroscopy (EIS), cyclic voltammetry, and time-domain analysis. It supports 2-, 3-, and 4-terminal measurements with exceptional resolution, handling both insulating and highly conductive materials. Integrated with the Alpha-A mainframe, it offers bandwidth up to 10 MHz and precision control of voltage and current for comprehensive material characterization.

The HVB series (300, 1000, 4000) are high-voltage test interfaces for Novocontrol’s Alpha-A dielectric analysis system, enabling accurate and safe impedance measurements under high AC and DC conditions. With voltage capabilities up to 4000 Vpp, they support wide frequency and impedance ranges, and are ideal for materials stress testing, nonlinear spectroscopy, and high-voltage engineering. Each unit integrates seamlessly with WinDETA software and Novocontrol’s temperature systems, offering complete control, calibration, and data acquisition.

The ZG2 and ZG4 are high-precision test interfaces for the Alpha-A Modular Measurement System, ideal for dielectric, conductivity, and impedance spectroscopy. ZG2 offers two-electrode measurements in a compact, flexible format, while ZG4 expands capabilities with 2-, 3-, and 4-electrode modes using driven-shield technology. Both models deliver outstanding accuracy and wide impedance coverage, making them perfect for advanced material and electronic component analysis.
